Heat setter for polyester knit fabrics

Heat setter for polyester knit fabrics
Heat setter for polyester knit fabrics
Product Code : 18
Product Description

Heat setter for polyester knit fabrics

Standard equips


Infeed part

  • The infeed part include infeed chamber,overfeeding device and width adjust device.
  • Overfeeding wheel is made of polyurethane material,it is durable and have long lifespan.overfeeding driven is controlled by inverter,overfeeding rate is steady.
  • Manual width adjust,safety and convient

Hot air setting part

  • Equips one set 11kw motor and aluminum alloy impeller,the triangle belt is driven between the motor and impeller shaft,it is realiable.the impeller  is light,run steady,low noize and big air volume.
  • Thermal oil heated type equips two sets high efficient heat exchanger,the heat exchange tube is steel aluminum compond fin tube,electric heated type equips 45pcs(each pc 3kw)electric tubes. The electric tube is controlled by group.
  • The pull filtering net is in front of the blower,the filtering net is 40meshstainess steel net,filter the fibers to avoid the pilus block the exchanger and nozzles.
  • The machine body is welded of super carbon angle steel and channel steel.
  • The four sides walls of the chamber are insulated panels with thickness 80mm,the Ptype rubber seal is dureable and can decrease the heat loss.
  • The heat chamber has the dust exhaust system,the blower is centrifugual motor,dust exhasust volume is controlled by air door.

Exit part

  • This part consists of rubber roller,plaiter device and coolant device.
  • The rubber roller adopts pneumatic pressure on system,and the pressure system equips air cylinder,reversing valve and so on.
  • Squeezing roller adopts super rubber,heat resistant,durable and longlife span.
  • Coolant device equips two sets axial flow blower,big air volume,air is evenly.

Control valve(thermal oil type)

The thermal oil control valve is proportion type,Corrugated pipe seal electric three way valve.


Electric heater(electric heat type)

The electric heater consist of electric tube,group control.
