Knit Fabrics Open Compacting Machine

Knit Fabrics Open Compacting Machine
Knit Fabrics Open Compacting Machine
Product Code : 25
Price And Quantity
  • Minimum Order Quantity
  • 1
  • Unit of Measure
  • Set/Sets
  • Price
  • $100,000-120,000 / Set USD ($)
Product Specifications
  • Product Type
  • Compacting Machine
  • Voltage
  • 350 (60hz) Volt/Ohm (v/ohm)
  • Dimension(L*W*H)
  • 6400X2750X2250 Millimeter (mm)
  • Weight
  • 10886 (12 tons) Kilograms (kg)
  • Warranty
  • 1 year
Product Description
We are offering Knit Fabrics Open Compacting Machines, which are embedded with feed device section. The device has fabrics guider, tension aligning frames, infra-red centering device, slide-proof paddle, machine body etc. The primary usage of this portion is to flat the fabrics and to move it in the center in an automatic manner. The head of the machines has manual weft straightener, screw spreading rollers, protecting panel, overfeed roller and rail and machine body. The primary usage of this part is to level the fabrics again and in-feed the fabrics to the bounds spreader in overfeeding variety. Cone-shaped stenter frame section is featured with overfeed pin on device, auto edge tracing device, screw spindles, protect panel, chain tension device etc. These machines of superior functionality come with parallel stenter frame section that consists of gemel, pin plate chain, chain driven device, width aligned device and protecting panel. The main role of this section is to steam and moisten the fabrics. Our exclusive Knit Fabrics Open Compacting Machines are available at competitive prices.

Features:
  • Ejecting nozzles, stopping valve, water collecting plate inserted in steaming box section.
  • Felt compacting units have two sets of auto tension correcting bars, which mechanically keep the invariant tension of the fabrics between the two drying rollers.
  • Cooling system section consists of centrifugal blower and cooling air box.
  • Plaiter section having fabric exit roller, tension controller, swing arms etc.

Technical Specification:

  •   Working width      1450mm(cylinder length 1550mm)
  •     Machine speed       3~30m/min
  •     Technical speed (actual speed when working)   15-20m/min(depends on process)
  •     Steam box steam consumption  60~100kg/hour
  •     Cylinder temperature     120~180
  •     Temperature control precision      ±1
  •     Cylinder heating pattern:
  •     Electric oil(consumption:25-30KW/H)
  •     Circulation oil( consumption 30000-50000Kcal/ H)
  •     Machine power          steam heated  10Kw
  •     Dimension(L*W*H)   6400X2750X2250mm
  •     Weight           4.5tons
Trade Information
  • FOB Port
  • Tianjin
  • Payment Terms
  • Telegraphic Transfer (T/T), Letter of Credit (L/C), Cash in Advance (CID)
  • Supply Ability
  • 100 Set/Sets Per Year
  • Delivery Time
  • 60 Days
  • Sample Available
  • Yes
  • Sample Policy
  • Contact us for information regarding our sample policy
  • Packaging Details
  • Wooden Pallets
  • Main Export Market(s)
  • Africa, Middle East, Western Europe, Eastern Europe, South America, North America, Central America, Australia, Asia
  • Main Domestic Market
  • All India
