Fabrics Heat Setting Machine

Fabrics Heat Setting Machine
Send Inquiry
Product Code : 53410000
Brand Name : TPY
Price And Quantity
  • Minimum Order Quantity
  • 1 Set
  • Price
  • 30,000-40,000 / Set USD ($)/Set
  • Price Range
  • 35000.00 - 38000.00 USD ($)/Set
Product Specifications
  • Type
  • Tubular heat setting machine
  • Product Type
  • Heat Setting Machine
  • Material
  • stainless steel
  • Capacity
  • 1 Ton/day
  • Printing Speed
  • 3-35m/min mm/m
  • Computerized
  • Yes
  • Automatic Grade
  • Automatic
  • Plate Type
  • Other
  • Print Direction
  • Other
  • Ink Type
  • Other
  • Weight
  • 4535 (5 Tons) Kilograms (kg)
  • Color Management
  • Other
  • Control System
  • PLC Control
  • Working Temperature
  • 220 Celsius (oC)
  • Power
  • 220V Volt (v)
  • Size
  • 7800*4900*3000
  • Width
  • 1400mm Millimeter (mm)
  • Weight (kg)
  • 5.5 Short Ton
  • Dimension(L*W*H)
  • 7800*4900*3000 Millimeter (mm)
  • Warranty
  • 1 year
Product Description

The Fabrics Heat Setting Machines we offer select hot air setting and have the maximum running temperature of 220°C. The machines are used for heat setting of the blender cotton fabrics and tubular polyester. These are additionally used for pre-setting of fabric in the steady-going sizing and plane surface. Highly efficient these machines have various standard tools and equipments. The in feed part of the products have overfeeding devices, and width adjust instrumentality. Overfeeding wheel integrated in the section is made with advanced polyurethane material that is exceedingly durable with a long service-time. Safety and convenient, the machines also incorporate a well controlled hot air setting part that equips one fixed motor of 11kw, aluminum alloy impellers and many more durable implements. Highly reliable the Fabrics Heat Setting Machines are light, steady-going and make low noise and ample air volume. The pull filtering net enclosed in the machines is located in the front of the blower. Filters are also integrated so as to avoid the filaments blocked in the nozzles and exchanger. The physical structure of the machine is welded of topnotch channel steel and carbon angle steel.


  • Heat chambers have the dust exhaust instrumentality.
  • Exit part are infix with plait-er device, rubber roller and coolant device.
  • Coolant device of machines equip two fits axial flow blower and large air volume
  • Control valves of thermal oil types, electric heaters of electric heat types inserted with electric tubes.

Technical Specification

Standard working width

double tube 1400mm

Maximum hot air temperature


Mechanical speed

3-20m/min(speed adjusted by inverter)

Machine overfeeding rate


Heating source


Thermal oil


Drive mode

three sections inverter control and double driven

Exit mode

plaiting or rolling

Motor power


Air pressure


Machine demision(L×W×H)


Machine weight

about 5T

Trade Information
  • FOB Port
  • Tianjin
  • Supply Ability
  • 100 Set Set/Sets Per Year
  • Delivery Time
  • 60 Days
  • Sample Available
  • Yes
  • Sample Policy
  • Contact us for information regarding our sample policy
  • Packaging Details
  • nude packing . machine is fasten well by steel in the container
  • Main Export Market(s)
  • Africa, Middle East, Western Europe, Eastern Europe, South America, North America, Central America, Australia, Asia
  • Main Domestic Market
  • All India
  • Certifications
  • ISO 9001 CE
