Felt Blanket Soft Calender For Cotton Fabrics
- Working width: Single tube：Max 1400 mm (overfeeding wheel inner side distance)
- Mechanical speed : 0--30m/min
- Drying cylinder surface working temperature <200℃
- Applicable steam pressure :0.4-0.6MPa
- Steam consumption:40Kg/h
- Applicable compressed air pressure:0.3-0.6Mpa
- Dimension(L×W×H): 2100×2800×2620mm
- Motor power : 9.74Kw
- Drying cylinder heat power : 24kW
- Machine weight : 3.0T
- Consistant infeeding device
- The device consist of machine frame,active roller,R fabrics storage box,slidepanel,pedal ,electrical control system.
- Overfeeding device and fabrics strecther.
- Steam moisturing device
- Soft setting device
- Ring felt 12mm thickness. Electric heated cylinder.
- Mechanical folding
- Rolling device
- Driven device
- The machine has 7motors totally,among them four sets are controlled by inverter,working speed is from 3mm to 30mmm/min.
- Electric control
- Delta inverter,Schnaider low voltage.
