knit fabrics dyeing finishing tubular balloon padder
- Minimum Order Quantity
- 1 SET Set
- Price Range
- 55000.00 - 58000.00 USD ($)
- 55000usd USD ($)
- Product Type
- Textile Machinery
- Machinery Type
- 10 SETS PER YEAR Fluid Ounce (oz)
- 220/380v Watt (w)
- 220V Watt (w)
- 48300*4620*1750MM Millimeter (mm)
- 5000KG Kilograms (kg)
- blue and grey
- 1 YEAR
DGRZ1600-2 series machine is used for impregnating soften agent and hydro-extractor process of the tubular fabrics, it can be substitute for centrifugal machine and wet expander. It is high efficient and easy to operate.
Main Technical Specification
3 45m/min(Inverter control the motor, speed is adjustable)
Appliable compressed air pressure
0.4 - 0.6Mpa
Machine figure(L x W x H)
5100mm x 2750mm x 2820mm
minimum 4.5 ton & Maximum 5.5 ton (Depending on Fabric GSM: 160, Fabric Width: 20 inch)
Turn table is driven by motor, it can turn clockwise or anticlockwise according to untwist needing. (Detwister is optional)
Fabrics open device (fabrics guide ring)
Fabrics guide rings position (fabrics working breadth) is adjusted through lead screw, lead screw is driven by motor, and the motor is controlled by pushbutton in control panel.
The infeed device is driven by motor; its speed can be adjusted by inverter, which can make sure the speed in phase. The web belt transports the fabrics, set with a moving adjust system to correct web belts running path; set with a lifting device draw by motor, lift or lower the in feed device facilitated to fabrics in feed.
Fabrics guide device
Set with Fabrics guide ring to ensure fabrics running in the middle of squeeze roll; set with 2sets limited switch control the fabrics tension between infeed roller and water squeezing roller, water squeezing roller and liquid squeezing roller to protect cloth guiding ring.
Air ballooning device
This part includes hand operation air spray and automatic ballooning, the air spray is the main ballooing device. The automatic ballooning device is controlled by two pieces single reverse valve. It is the assistant device.
Water squeezing device and liquid squeezing device
Each device consists of 2 sets(four pieces) rubber roller made of special material and 2 sets air cylinder, each air cylinder is controlled by single reverse valve, the valve power on, the squeezing roller pressurizing; power off, squeezing roller apart. The pressure of the squeezing roller is adjusted by two sets reduce valve. Set with 3-position rotary switch control motion of magnetic valve. The water squeezing device and softener expression device are driven by one motor separately, the two motors are controlled by inverter and speed can be adjusted, which made the fabrics run in non tension situation.
Tension adjust device
Set with a regulation-resistance to adjust tension between liquid squeezing roller and delivery device.
Fabrics exit device
This device is driven by inverter controlled motor ensure synchronous running.
The heating device consists of heating pipe, thermo-couple, filter, reverse valve, pneumatic driven stop valve and steam trap, it can keep liquid temperature constant automatically
It consists of blender heating pipe water injection pipe; its function is blend softener and water fully.
The whole machine has 6 sets driving motors, among them in-feed motor water squeezing motor, softener expression motor and plaiting motor are droved by inverters, the inverter is controlled by synchronous controller. rotate "total adjust" knops, the overalls speed changed. Moreover the speed of feed motor water squeezing motor, softener expression motor and plaiting motor can be adjusted individually. Set with pushbutton on control panel control Breadth motor and lift motor running clockwise or anticlockwise. "start" and "stop" pushbutton control Blender motor's running.
The inverter is Delta brand of Taiwan. Low voltage appliance is Schneider of France.
Main parts of the machine
Inverter:Delta of taiwan 4sets
Water squeezing roller: acid base resistant rubber roller two sets
Softener expression roller: acid base resistant rubber roller two sets
Gear box motor: 3kw 2sets
Gear box motor: 0.75kw 4sets
Gear box motor: 1.5kw 2sets
Infeed web belt: 3175mmx1640mm Du pont of USA 2pcs material is imported from Du pont and made in China
Bearing: made in China
Pneumatic components: shanghai of China
Rough belt: 40x2mm
Channel steel, corner steel: 10#, 5# Ji steel
Steel plate: thickness 10, 3 shanghai Bao steel.
Painting(machine skin coating): Tianjin of China
Digital temperature controller: Shanghai
Low voltage electric sets(like switch, indicator, relay): Schneider of France
Chains: Hangzhou of China
Triangle belt: Jinan of China
Thermal couple: shanghai of China
- FOB Port
- tianjin qingdao
- Payment Terms
- Telegraphic Transfer (T/T), Letter of Credit at Sight (Sight L/C), Letter of Credit (L/C)
- Supply Ability
- 10 Set sets Per Month
- Delivery Time
- in 2months Months
- Sample Policy
- Contact us for information regarding our sample policy
- Packaging Details
- stander packing way
- Main Export Market(s)
- Eastern Europe, South America, North America, Central America
- Main Domestic Market
- All India
