Send InquiryKnit Fabrics Open Width And Tubular Tensionless Dryer
Product Details:
- Manufacturing Year 2020 Years
- Speed 100 m/m
- Fabric width 2800 Millimeter (mm)
- Fabric Type Tubular knitting fabric cotton or blend
- Weight 20000 Kilograms (kg)
- Voltage 220/380 Volt (v)
- Applicable Material woven.knitting .wool
- Supply Ability : 10 Set Per Year
Price And Quantity
- 150000.00 - 160000.00 USD ($)
- 150000 USD ($)
- 1 Set
Product Specifications
- 2020 Years
- 100 m/m
- 2800 Millimeter (mm)
- Tubular knitting fabric cotton or blend
- 20000 Kilograms (kg)
- 220/380 Volt (v)
- woven.knitting .wool
- 32300*4620*1750 Meter (m)
Trade Information
- tianjin qingdao
- 10 Set Per Year
- 60 Days
- Contact us for information regarding our sample policy
- stander packing way
- All India
- ISO 9000 CE
Product Description
Knit Fabrics Open Width And Tubular Tensionless Dryer
The fabrics stay long time in the drying chambers; so that the water inside the fiber and outside the fiber is uniform, eliminate the difference of the fabrics two sides radically. If fabrics dried by single pass dryer, inside and outside water of the fiber is difference, outside is too dry and inside is too wet, after treated, the fabrics colors changed, reduce the fabrics quality. But the three pass relax dryer had overcome this point.
The fabrics treated by this machine have soft hand-feeling, low water shrinkage and fabrics quality is enhanced. It has the advantage of saving energy Âhigh efficient, high automatic and easy to operate. So it has become one of the most ideal drying devices.
The appearance of the machine is beautiful, the entire frame, chambers, panels are made of super carbon steel, and surface are specially treated.
Technical parameter
| Web belt width | 2000MM/2200mm/2400mm/2600mm/2800mm/3000mm/3200mm |
| Machinical speed | 5-34M/MIN |
| Overfeeding rate | -20 +50% |
| Fabrics length in the drying chambers | 58meters (6.3meters per chamber.) |
| Heating dimension of each heat exchanger | 220m² |
| Max evaporation capacity | 140 180Kg/H chamber |
| Dimension(LXWXH) |
Each chamber length 2100mm |
| Chambers quantity | six chambers |
| Total weight | 35 tons (each chamber 5tons) |
| Power | 149.85Kw (each chamber 22kw) |
Machine structure:
- Fabrics infeed section
- Fabrics exit section
- Controlling valve
- Thermo oil heating method adopts
- Bealz brand electric three way valves that made in Germany
- Steam heated:adopts pneumatic direction changing valve.
- Heat recycle system
- Except the first chamber, the left chambers equips heat recycle sytem per chamber.
Electrical control
- Electric controls adopts programme controlling method, equips blowers starting in sequence system, faulty fabrics protecting system, emergency cooling system, counter-clockwise system
- Electric component adopts Taiwan Delta inverter, France Schneider low voltage apparatus. temperature controller brand is Honeywell of America(±3).
